GLC-LH-SMD Overview

Cisco GLC-LH-SMD 1000BASE-LX/LH SFP is made for Both Multimode and Single-Mode Fibers.

The 1000BASE-LX/LH SFP, compatible with the IEEE 802.3z 1000BASE-LX standard, operates on standard single-mode fiber-optic link spans of up to 10 km and up to 550 m on any multimode fibers. When used over legacy multimode fiber type, the transmitter should be coupled through a mode conditioning patch cable. 1300-nm wavelength, extended operating temperature range and DOM support, dual LC/PC connector.

This Figure shows the appearance of GLC-LH-SMD.

GLC-LH-SMD Appearance

The table provides cabling specifications for the SFPs that you install in the Gigabit Ethernet port.

Note that all SFP ports have LC-type connectors, and the minimum cable distance for all SFPs listed (multimode and single-mode fiber) is 6.5 feet (2 m).

SFP Port Cabling Specifications

Product

Wavelength (nm)

Fiber Type

Core Size (μm)

Modal Bandwidth (MHz* Km)***

Operating Distance (m)

1000BASE-SX

(GLC-SX-MMD )

850

MMF

62.5

160 (FDDI-grade)

220 (722 ft)

62.5

200 (OM1)

275 (902 ft)

50

400 (400/400)

500 (1,640 ft)

50

500 (OM2)

550 (1,804 ft)

50

2000 (OM3)

1000 (3281 ft)

1000BASE-LX/LH

(GLC-LH-SMD)

1310

MMF*

62.5

500

550 (1,804 ft)

50

400

550 (1,804 ft)

50

500

550 (1,804 ft)

SMF

-**

-

10,000 (32,821 ft)

1000BASE-EX

1310

SMF

-**

-

40,000 (131,234 ft)

1000BASE-ZX

(GLC-ZX-SM )

(GLC-ZX-SMD )

1550

SMF

-

-

Approximately 70 km depending on link loss

1000BASE-BX-U

1310

SMF

-**

-

10,000 (32,821 ft)

1000BASE-BX-D

Cisco SFP (Mini-GBIC) Transceiver Module Single Mode Gigabit / GLC-LH-SMD ( O )

Rating is 4.7 out of five stars based on 31 reviews
SKU: GLC-LH-SMD
EGP4,500.00Price
